Industrial engraving machine(CNC Router)

XD6080 engraving machine(industrial) Machine Features: 1. The box structure to ensure high rigid, high precision. 2. High-power spindle motor for high efficent processing. 3. The Square Raceway, which space can be ajusted and life span more than 10 years. 4. With Pond, the workpiece can be caved in the pond. Technical Parameter: type XD6080 X,Y working stroke 800*600mm Z working stroke 160mm Precision 0.005mm Spindle power 2.2KW Speed of spindle 6000-24000RPM Speed of cutting 30-6000mm/min Diameter of cutting 12.7mm Power supply AC220V Driving motor DC servo Max workpiece weight 200kg Optional :double or many spindle motor,scanner,ATC. Perfomance Features and Application Field: The box structure of the machine body,the table and the horizontal beam causes maximum machine rigidity,the rolling way,the ball screw,and servo motors,are all provided by world famous manufacturer to ensure high precision,reliability and endurance.It is suitable for engraving of copper,brick,wood ,marble,aluminum,etc material.
